Best Practices For Electroplating In Aerospace Applications

by | Jun 8, 2023

Electroplating is an essential technique in the aerospace industry, utilized to apply a thin metal layer onto a substrate. This process enhances the strength, durability, and corrosion resistance of components. Achieving top-quality results in electroplating demands a combination of specific conditions and expertise.

This article will provide an overview of the best practices for electroplating in aerospace applications, including the benefits, common finishes, and quality control techniques. Additionally, the importance of electroplating in the aerospace industry and the many applications of electroplating will be discussed. With the knowledge provided, you can ensure your aerospace projects are built to the highest quality and safety standards.

Looking for a trusted and reputable electroplating partner in the aerospace industry? Check out Valence – the world’s largest independent aerospace surface finishing company. We’re AS9100D certified and have extensive experience in electroplating for aerospace applications. Our state-of-the-art facilities, rigorous quality control processes, and commitment to customer satisfaction make us a trusted choice for aerospace electroplating needs.

Contact us today to discuss your specific requirements and discover how our expertise can contribute to the success of your aerospace projects!



What Is Electroplating?

Electroplating is a process that involves coating a metal surface with a thin layer of another metal, typically for the purpose of enhancing properties such as corrosion resistance, wear resistance, electrical conductivity, or aesthetics.

This technique is achieved through hydrolysis, where an electric current promotes the reduction of dissolved metal cations, resulting in a coherent metal coating on the electrode. In some cases, electroplating is also applied for the electrical oxidation of anions on a solid substrate, like the formation of silver chloride electrodes.

From aviation and defense to medical/life sciences and space and communication systems, electroplating has diverse applications across various industries. It not only modifies surface features to improve aspects like corrosion protection, lubricity, and abrasion resistance but can also be used to build thickness or create objects through electroforming.(1)



How Does Electroplating Work?

Electroplating, also known as electrodeposition, is a process where a thin layer of metal is deposited onto the surface of a workpiece, referred to as the substrate. This technique employs an electric current to reduce dissolved metal cations, ultimately forming a metal coating in an electrode.(2)

In this process, the anode is connected to the positive terminal, while the cathode, or the metal to be plated, is connected to the negative terminal. Both are immersed in an electrolyte solution and linked to an external direct current (DC) power supply.

Upon applying DC power, the anode undergoes oxidation, causing metal atoms to dissolve in the electrolyte solution. These ions are then reduced at the cathode, forming a coating.(2)



The Benefits Of Electroplating In Aerospace

Electroplating is a critical process in the aerospace industry, applying a thin metal layer to a substrate, such as a metal part or component. It offers numerous benefits, including:

Corrosion Protection: Electroplating shields components from corrosion, wear, and abrasion, increasing their lifespan.

Aesthetics: It can enhance the appearance of components, making them more visually appealing.

Electrical Conductivity: Electroplating can improve electrical performance, an essential aspect of aerospace components.

Weight Reduction: It can help reduce component weight, leading to lower fuel costs and increased aircraft efficiency.

Increased Durability: Electroplating withstands extreme temperatures and conditions, which is vital for aircraft exposed to harsh environments.

Reduced Friction: The thin metal layers can decrease friction, which is crucial for aircraft experiencing high speeds and turbulence.

Cost Savings: By protecting components from corrosion and wear, electroplating reduces the need for frequent repairs or replacements. This ultimately leads to cost savings for aerospace companies.



Electroplating Vs. Electroforming

Electroplating and electroforming are two distinct processes used to deposit metal onto a substrate, both involving the application of electrical current. While they share similarities and rely on electrodeposition, their results and applications differ significantly.

Electroplating is a surface-level process where a thin layer of metal is deposited onto a substrate to improve properties such as corrosion resistance, wear resistance, and electrical conductivity or for decorative purposes like adding gold or silver layers. This process enhances the appearance or functionality of the object, and the metal coating becomes an integral part of the surface it is deposited on.

Conversely, electroforming is a three-dimensional process employed to create an entire object out of metal through the deposition of layers. The metal is deposited in a liquid bath, building up the object until the desired shape is achieved. Once complete, the metal is removed from the bath, and the object is separated from the model it was formed on.



Common Electroplated Finishes

Electroplating is a process that uses an electric current to deposit a thin layer of metal onto a substrate. This process is used to create a variety of finishes, from smooth and glossy to matte and textured.

Here are some common electroplated finishes:



Nickel And Zinc-Nickel Electroplating

Nickel and zinc-nickel electroplating are favored choices for aerospace components due to their outstanding corrosion and wear resistance.

Nickel electroplating involves depositing a thin layer of nickel onto a substrate, either as a single coating or combined with other metals, like copper or chromium, to form a more robust alloy.

Meanwhile, zinc-nickel is typically applied for corrosion protection, serving as a sacrificial coating that corrodes before that base material.(3)

Both processes contribute to reduced friction, enhanced corrosion protection, and an improved aesthetic appeal of the component.



Copper Electroplating

Copper electroplating is a preferred option for aerospace components due to its affordability, excellent corrosion resistance, and adaptability to various metals.

The process involves depositing a thin copper layer onto a metal substrate by immersing it in a copper plating bath containing an electrolyte solution and copper ions.(4) An electric current is then applied, attracting the copper ions to the substrate and depositing them on the surface.

This technique creates a corrosion and abrasion-resistant copper layer, making it an ideal solution for aerospace applications.



Gold Electroplating

Gold plating is highly suitable for aerospace applications due to its exceptional corrosion resistance, electrical conductivity, low contact resistance, and remarkable protection against wear and tear. Its aesthetic appeal also makes it a popular choice for components exposed to extreme conditions.

The gold electroplating process involves depositing a thin layer of gold onto a metal surface, enhancing the appearance and durability of components.

This method offers superior defense against corrosion, wear, and environmental elements while reducing friction, making it ideal for moving parts in the aerospace industry.



The Importance Of Electroplating In The Aerospace Industry

The importance of aerospace plating encompasses various factors that contribute to the overall performance and durability of aerospace components.

  1. Higher Electrical Conductivity

By depositing a thin layer of conductive material on the surface, such as copper or gold, electroplating enhances the flow of electrical current, ensuring efficient operation of electrical systems and reducing the risk of electrical failures.

This is crucial in aerospace applications where reliable electrical conductivity is necessary for communication, navigation, and control systems.

  1. Extended Lifespan Of Parts And Components

Electroplating enhances protection against external factors that can lead to corrosion and wear, ultimately lowering replacement costs in the long run.

  1. Stronger Metal Substrate

Depending on the chosen substrate, electroplating can significantly increase the strength of your product. Typical benefits include enhanced hardness, corrosion resistance, heat resistance, and abrasion prevention.

  1. Increased Resistance

Metal plating also provides increased resistance to chemical attack, oxidation, and other environmental factors that aerospace components may encounter during operation. This helps to maintain the integrity and functionality of the parts over time.

  1. Improved Aesthetic Appeal

Polishing and plating processes enhance the appearance of the original metal by cleaning, smoothing, and removing flaws. A variety of finishes, such as matte, glossy, or textured, can be achieved, along with decorative accents like color application.

At Valence, we offer unique selective plating and precision masking techniques that are specifically designed for aerospace applications. These advanced techniques allow for precise and targeted plating, ensuring that only specific areas of a component are plated while others remain unaffected.

Request a quote on electroplating for your application, or contact us today for more information.



Understanding The Electroplating Process And Principles

Electroplating involves passing an electric current through a solution containing the metal to be deposited. This process results in an even layer of metal on the substrate, with its thickness determined by the current and duration.

To achieve the desired outcome, it’s crucial to understand the principles and processes of electroplating.

Preparing the substrate through cleaning and activation is the first step, ensuring proper adhesion of the metal layer.

The substrate is then immersed in a plating bath, and a direct current is applied to deposit the metal.

Careful monitoring of the current and process duration is necessary to produce an even and precise finish.

Different metals, such as copper, nickel, gold, and silver, require unique processing methods during electroplating.



Best Practices For Selecting And Preparing Substrates

When it comes to electroplating, selecting and preparing the substrates correctly is essential for achieving optimal results.

Here are four best practices when selecting and preparing substrates:



Clean

A crucial aspect of the electroplating process is cleaning the substrate. Proper cleaning ensures that the substrate is free from dirt, dust, and other contaminants, which could otherwise affect the quality of the electroplated finish.

The cleaning process typically involves:

  1. Chemical Cleaning

Utilizing degreasing agents, alkaline solutions, and etchants to remove contaminants from the substrate surface.

  1. Mechanical Cleaning

Employ methods such as abrasive blasting, ultrasonic cleaning, and mechanical polishing to clean the substrate effectively.



Activate

A vital step in the electroplating process is substrate activation. This process prepares the substrate by creating a surface that enables metal ions to bond effectively.

Typically, a chemical solution is used for activation, with common activators such as sulfuric acid, chromic acid, hydrochloric acid, and nitric acid. The choice of activator depends on the substrate’s material, as some metals necessitate specific solutions.

The activation process usually involves soaking or dipping the substrate in the activator solution, followed by a thorough rinse. This step guarantees a clean substrate, free from contaminants that might impact the electroplating outcome.

Achieving a high-quality finish and even metal deposit on the substrate hinges on proper activation.



Mask

Achieving high-quality results in electroplating requires a crucial step known as masking. This process involves covering specific areas of the substrate that should not be electroplated. Protective coatings or materials, such as tape, paint, or rubber, are applied to these areas to prevent plating.

Masking also serves to shield parts that must not be exposed to the plating solution, including threads or electrical contacts.

It’s essential to remember that masking should be performed before the activation process, and the protective materials must be compatible with the plating solution.

After the plating process, it’s important to remove the masking material thoroughly to reveal the final result.



Monitor

Electroplating requires constant process monitoring to provide the correct finish. Regular intervals of observation ensure that the correct parameters, such as current density, temperature, and others, are maintained throughout the procedure.

Monitoring also extends to the plating bath, checking that it remains free of contaminants and that the plating solution stays active.

Furthermore, close attention should be paid to the substrate’s surface to confirm the desired finish is achieved. Visual inspections can reveal defects like pinholes, pits, or discoloration.

In case of any defects, halt the plating process, identify the cause, and implement corrective measures.



Quality Control And Inspection Techniques For Electroplating

Quality control and inspection techniques play a crucial role in guaranteeing the highest quality and safety standards for electroplated aerospace components.

The electroplating process involves several steps, from pre-treatment to post-treatment, to create corrosion-resistant products with consistent finishes.

Pre-Treatment

The substrate must be cleaned, degreased, and etched to ensure it is free of dirt and contaminants and ready for electroplating. Inspect the substrate to confirm it meets the requirements for the process.

Electroplating Process

Ensure the correct materials and chemicals are used, and monitor the electroplating bath for the proper current, voltage, and temperature. Test the bath regularly to verify it is contamination-free and maintains the correct chemical levels.

Inspection

After electroplating, check the substrate for uniformity of finish, thickness, and adhesion. Identify and correct any defects if possible.

Post-Treatment

Perform processes like annealing and passivation to enhance the substrate’s corrosion resistance and consistent finish. Inspect the substrate for any defects that may have occurred during the electroplating process.

By adhering to the proper quality control and inspection techniques, aerospace components can be produced with a consistent finish and corrosion resistance, ensuring the highest quality and safety standards.



Quality control and inspection



The Many Applications Of Electroplating

Electroplating plays a crucial role in numerous aerospace applications, offering a wide range of benefits. It is commonly employed to help with:

Corrosion Protection: Electroplating is widely used in the aerospace industry to protect components such as landing gear, control surfaces, and engine parts from corrosion.

Decorative Finishes: It is also applied to create visually appealing finishes on components like interior cabin trim, decorative panels, and exterior aircraft parts.

Wear Resistance: Electroplating improves wear resistance on components by depositing a thin layer of metal onto their surfaces. This enhancement is vital in aerospace, where parts must withstand extreme temperatures and pressures.

Electrical Insulation: It can also be used to provide electrical insulation on select components.

Thermal Barrier Coatings: In aerospace applications, electroplating is employed to apply thermal barrier coatings made of ceramic materials. These coatings protect components from extreme temperatures experienced during flight, ensuring proper adhesion and protection.



With Knowledge, Ensure Your Aerospace Project Is Built To The Highest Quality, Safety Standards

Understanding the principles of electroplating in aerospace applications and adhering to best practices for selecting and preparing substrates is crucial to ensuring your aerospace project meets the highest quality and safety standards.

Proper cleaning, activating, masking, and monitoring of the process, along with employing quality control and inspection techniques, guarantee desired results. Furthermore, complying with strict aerospace industry regulations and guidelines for electroplating is essential for aircraft and passenger safety.

Therefore, you should partner with a reputable surface finishing company like Valence that checks all the boxes in terms of expertise, experience, and compliance with industry standards!

Not only are we AS9100 and NADCAP-approved, but also have a proven track record of delivering high-quality electroplating services for aerospace applications. Our team of skilled technicians is well-versed in the intricate processes involved in electroplating, and we utilize state-of-the-art equipment and advanced techniques to achieve superior results.

By collaborating with us, you can have confidence that your aerospace project will undergo electroplating with meticulous attention to detail and adherence to the strictest quality and safety standards.

Request a free quote or contact us today for a comprehensive assessment of your electroplating needs in the aerospace industry.



Aerospace Project



Final Thoughts

Navigating the complexities of electroplating in the aerospace industry can be challenging, but it doesn’t have to be! By understanding the principles and best practices discussed above, you can carefully select a reputable surface finishing company like Valence and ensure your aerospace project is built to the highest quality and safety standards.

So look no further – request a quote or contact us today to get started on your electroplating journey with confidence and peace of mind!

For additional topics of interest, check out:



Sources:

  1. BYJUS. (2018, July 21). Electroplating Process. BYJUS; Byju’s. https://byjus.com/chemistry/electroplating-process/.
  2. How Does Electroplating Work? (2018, December 7). PRV Engineering Blog. https://blog.prv-engineering.co.uk/electroplating-applications/#:~:text=Electroplating%20uses%20an%20electric%20current.
  3. Zinc Nickel Plating – Chem Processing Inc. (n.d.). Www.chemprocessing.com. http://www.chemprocessing.com/page.asp?pageid=70&.
  4. Rapid Direct. (2022, April 27). Copper Electroplating: How It Works and Its Applications. Rapid Direct. https://www.rapiddirect.com/blog/copper-electroplating/.



FAQs

What metal is used for aerospace?

In aerospace applications, a variety of metals are used depending on the specific requirements of the components.

Some commonly used metals include aluminum, titanium, stainless steel, and nickel-based alloys. These metals are chosen for their strength, lightweight properties, corrosion resistance, and ability to withstand high temperatures.



What chemicals are used in aerospace?

Commonly employed chemicals include sulfuric acid, hydrochloric acid, nickel sulfate, chromium trioxide, and various proprietary plating solutions.

These chemicals are carefully selected to ensure compatibility with the metal being plated and to meet the specific requirements of the aerospace industry, such as durability, adhesion, and resistance to environmental factors.



What is the main purpose of electroplating?

The main purpose of electroplating is to improve the corrosion resistance and wear resistance of a substrate material. It is also used to create a decorative finish on surfaces, as well as to provide electrical conductivity.



What is the application of electroplating?

Electroplating is used in a wide range of industries, including aviation, defense, medical/life sciences, and space and communication systems. It’s used to protect metals from corrosion, improve the appearance of surfaces, and provide electrical conductivity.



What are the conditions for electroplating?

The conditions for electroplating depend on the type of material being plated and the desired results. But generally, the temperature and pH of the plating solution must be carefully controlled, and a current must be applied to the substrate material to facilitate the electroplating process.
